Talas M/X/XX/S vertical water heaters | Stainless steel water heaters

Talas S/M/X/XX vertical water heaters

Vertical water heaters TALAS M/X/XX capacity 30, 50, 60, 80 ,100, 120 and 150 litres are produced in several dimensions for one model (capacity).
So, for example the model of 80 litres is produced in three dimensions, thus solving the space problems and mounting on the existent cantilevers.
The installation of the thermostat of the best quality - EGO Germany contributes to the exceptional quality of this type of heater.

Tip-V*	S30V	M30V	S50V	S60V	S80V	M80V
Zapremina (l)	30	30	50	60	80	80
Priključne mere
A (mm)	560	480	840	970	1150	995
B (mm)	190	210	190	210	200	220
C (mm)	70	100	70	70	70	100
D (mm)	360	420	360	360	360	420
E (mm)	250	220	490	610	745	620
Tehničke karakteristike
Radni pritisak (MPa)	0,6
Max. temperatura (°C)	85
Materijal kazana	INOX
Izolacija m. vuna (mm)	35
Vreme zagrev. 10-75 °C (min)	67		112	135	181
Termostat	regulacioni + zaštitni
Sigurnosni ventil 9 bar	da
Mg zaštitna anoda	da
Stepen zaštite	IP 24
Snaga grejača (W)	2000
Napon (V)	230V ~ 50 Hz
Struja (A)	8,7
* Bojler ima dve pločice-nosači na zid

univerzalnog nosača (Sl.2)

Tip-V	M50V	X50V	M60V	X80V	XX80V	X100V	XX100V	XX120V	XX150V*
Zapremina (l)	50	50	60	80	80	100	100	120	150
Priključne mere
A (mm)	750	620	815	880	750	1050	860	1000	1150
B (mm)	200	180	150	210	190	210	170	210	180
C (mm)	100	120	100	120	140	120	140	140	140
D (mm)	420	450	420	450	480	450	480	480	480
Tehnički podaci
Radni pritisak (MPa)	0,6
Max. temperatura (°C)	85
Materijal kazana	INOX
Izolacija m. vuna (mm)	30
Vreme zagrev. 10-75 °C (min)	112	112	135	181	181	227	227	274	226
Termostat	regulacioni + zaštitni
Sigurnosni ventil 9bar	da
Mg zaštitna anoga	da
Stepen zaštite	IP 24
Snaga grejača (W)	2000								3000
Napon	230V ~ 50 Hz
Struja (A)	8,7								13,0
XX150V* - Bojler ima dva UNIVERZALNA nosača i odstojnik (Sl.2)
